Precision Magnetic Snap Fasteners & Buttons (10mm, 12mm, 14mm+) for Professional Leatherwork, Luggage & Apparel
所属分类： Magnet button
产品简介：Pei Cheng Garment&bags Accessories Co., Ltd
产品详情
Precision Magnetic Snap Fasteners & Buttons (10mm, 12mm, 14mm+) for Professional Leatherwork, Luggage & Apparel
Engineered for demanding closures in leather goods, luggage, and apparel, our industrial-grade magnetic snap fasteners deliver reliable holding power with seamless operation. Available in 10mm, 12mm, 14mm, 15mm, 16mm, 18mm, and 20mm diameters, these components feature corrosion-resistant metal alloys and neodymium magnets rated for 50,000+ cycles.
Key Technical Advantages:
0.9-1.6mm Ultra-Low Profile after installation
316L Stainless Steel or Nickel-Plated Brass housings
N35-N52 Grade Neodymium Magnets (pull force: 0.8kg-4.2kg)
Temperature Resistance: -30°C to 120°C
Universal Compatibility with manual/press setting tools
Technical Specifications & Application Matrix
| Size (Ø) | Magnet Grade | Max. Pull Force | Material Options | Primary Applications |
|---|---|---|---|---|
| 10mm | N35 | 0.8kg | Brass (Ni/Ag), Steel (Bk/Zn) | Purses, Card Wallets, Key Fobs, Lightweight Apparel |
| 12mm | N38 | 1.3kg | Brass (Ni/Au), Stainless Steel | Handbags, Small Cases, Vests, Craft Projects |
| 14mm | N42 | 2.1kg | Brass (Ni/Bk), Stainless Steel | Leather Totes, Jackets, Denim, Suit Closures |
| 15mm | N45 | 2.7kg | Brass (Ni/Cu), Steel (Zn) | Luggage Straps, Messenger Bags, Tool Rolls |
| 16mm | N48 | 3.2kg | Brass (Ni/Ni), Stainless Steel | Duffel Bags, Heavy Jackets, Workwear |
| 18mm | N50 | 3.8kg | Stainless Steel, Brass (Ni) | Travel Luggage, Upholstery, Industrial Gear |
| 20mm | N52 | 4.2kg | Stainless Steel, Zinc Alloy | Equipment Cases, Heavy-Duty Tarps, Safety Gear |
Finishes: Nickel (Ni), Silver (Ag), Gold (Au), Antique Copper (Cu), Black Oxide (Bk), Zinc (Zn)
Application-Specific Performance
1. Leather Goods & Cases
Purses/Handbags: 12mm-14mm snaps for flap closures (tested with 3mm full-grain leather)
Wallets: 10mm low-profile units for card slot retention
Luggage/Travel Cases: 16mm-20mm with N48+ magnets for vibration resistance
2. Apparel & Outerwear
Denim Jackets: 14mm corrosion-resistant models withstand frequent washing
Suits/Vests: 10mm-12mm concealed closures maintain drape integrity
Technical Outerwear: 15mm-16mm units operate in -20°C environments
3. Commercial & Craft Applications
Luggage Manufacturing: 18mm-20mm reinforced anchors for handle straps
Scrapbooking: 10mm micro-snaps for memory box closures
Upholstery/Craft: 14mm-16mm for cushion covers and tool pouches
Installation Guidelines
Material Thickness: Compatible with 0.8mm (silk) to 4.5mm (heavy leather)
Tool Requirements:
Manual press: For prototypes/small batches
Industrial presses: 2-5 ton capacity for volume production
Reinforcement: Use 25mm polyester backing washers for stretch fabrics
Quality Validation
Pull Force Testing: ASTM F2594 standard compliance
Environmental Tests: 72hr salt spray (ASTM B117), UV exposure (ISO 4892)
Cycle Testing: 50,000+ engagements on automated rigs
Industry-Specific Configurations
Luggage Makers: 18mm units with 1.2mm stainless steel caps
Fashion Houses: 12mm-14mm antique brass/gold for heritage leather
Workwear Suppliers: 16mm black oxide snaps for high-visibility gear
Ordering Specifications
MOQ: 500 units per SKU (mixed sizes accepted)
Certifications: RoHS, REACH, Prop 65 compliant
Packaging: Industrial reels (500pcs) or bulk trays (2,000pcs)
